MAGNETI MARELLI 360406046500 (AutoAnděl: 1)
Brzdový kotouč
Dostupnost
| Průměr v mm | 235 mm |
|---|---|
| Výška [mm] | 43,2 mm |
| typ brzdového kotouče | vnitřně větráno |
| Síla brzdového kotouče [mm] | 18 mm |
| Minimální tloušťka [mm] | 16 mm |
| Vnější průměr [mm] | 235 mm |
| Počet děr | 4 |
| Utahovací moment [Nm] | 103 Nm |
| Kruhový vyvrt O 2 [mm] | 55 mm |
| Status | normální |
| Skupina položky | Brzdový kotouč |
| TOYOTA YARIS (_P1_) 1.0 (SCP10_, SCP10R) 50 kW ( 1SZ-FE ) |
|
||
| TOYOTA YARIS VERSO (_P2_) 1.3 (NCP20_, NCP22_, NCP20R, NCP22R) 63 kW ( 2NZ-FE ) |
|
||
| TOYOTA YARIS (_P1_) 1.3 (NCP10, SCP12_) 63 kW ( 2NZ-FE ) |
|
||
| TOYOTA YARIS (_P1_) 1.4 D-4D (NLP10_, NLP10R) 55 kW ( 1ND-TV ) |
|
||
| TOYOTA YARIS (_P1_) 1.3 (SCP12_, SCP13_, SCP12R, SCP13R) 64 kW ( 2SZ-FE ) |
|
||
| TOYOTA YARIS (_P1_) 1.0 (SCP10_, SCP10R) 48 kW ( 1SZ-FE ) |
|
| TOYOTA | 43512-52020 |
|---|---|
| TOYOTA | 43512-52050 |
| TOYOTA | 4351252010 |
| TOYOTA | 4351252020 |
| TOYOTA | 4351252050 |
| BOSCH | 0 986 478 582 |
|---|---|
| BREMBO | 09.7825.10 |
| BREMBO | 09.7825.14 |
| BREMBO | 09.7825.75 |
| BREMBO | 09782575 |
| BOSCH | 0986478582 |
| BOSCH | 0986479244 |
| MAPCO | 15559 |
| sbs | 17027 |
| A.B.S. | 17027 OE |
| A.B.S. | 17027S |
| sbs | 1815203348 |
| sbs | 1815204582 |
| sbs | 1815204588 |
| VALEO | 186587 |
| METELLI | 23-0552 |
| METELLI | 230552 |
| ATE | 24.0118-0131.1 |
| ATE | 24011801311 |
| FEBI BILSTEIN | 27399 |
| MEYLE | 30-15 521 0020 |
| ATE | 418131 |
| PAGID | 50301 |
| JURID | 562169J |
| ZIMMERMANN | 590256900 |
| QUINTON HAZELL | 6618.10 |
| SWAG | 81 92 7399 |
| TRISCAN | 8120 13156 |
| TEXTAR | 92103600 |
| TEXTAR | 92103603 |
| TEXTAR | 98200103601 |
| DELPHI | BG3519 |
| FTE | BS5117 |
| FERODO | DDF1084 |
| FERODO | DDF1084C |
| TRW | DF4112 |
| Brake ENGINEERING | DI955884 |
| NIPPARTS | J3302124 |
